Metal Frame Anchor

Size: M6-M24, 1/4-1''
Material: Carbon steel, Stainless steel
Coating: Zinc plated, Yellow zinc plated
Standard: DIN, ANSI, BSW, GB

Category:

Anchor Series

E-mail:

info@hfastfix.com

Inquire Now

Description

Metal frame anchor designed to be used in conjunction with bolts or screws to create a secure connection to concrete, masonry, or other solid materials.

Features

★ Cylindrical body: The main part of the anchor is a hollow cylinder.
★ Internal threads: The threaded end allows for the attachment of a bolt or screw.
★ Expansion design: When the bolt or screw is tightened, the anchor expands within the pre-drilled hole, creating a secure hold.
★ Material: Sleeve anchors are typically made of steel or stainless steel for strength and durability.

Dimensions

Size: M6-M24, 1/4-1''
Material: Carbon steel, Stainless steel
Coating: Zinc plated, Yellow zinc plated
Standard: DIN, ANSI, BSW, GB
Grade: 4,5,6

Technical Data

Size	Anchor diameter (mm)	Sleeve length (mm)	Screw size
M8×72	8	72	M5×82
M8×92	8	92	M5×102
M8×112	8	112	M5×112
M8×132	8	132	M5×142
M8×152	8	152	M5×162
M8×172	8	172	M5×182
M10×72	10	72	M6×82
M10×92	10	92	M6×102
M10×112	10	112	M6×112
M10×132	10	132	M6×142
M10×152	10	152	M6×162
M10×182	10	182	M6×192
M10×202	10	202	M6×212

Production scene

About our company

Hebei Hengcheng Fastener Co., Ltd is a National High-tech Enterprise, established in Hebei Yongnian in 1998, specializing in the production and sales of fasteners including Nuts, Bolts, Drop in anchor, Strong anchor, Self-drilling screw, Self-tapping screw, Drywall screw and Customized cold forging parts. The company covers an area of 70,000 square meters with about 150 staff at present, and among which there are over 30 senior technicians and 30 salesmen. To guarantee the quality, the company applies the world-advanced facilities for production including machines of cold forging,hot forging, threading,wire drawing,annealing,heat treatment and other ancillary equipment. With more than 20 years’ development, the company becomes one of the largest manufacturing enterprises in the fastener industry of North China.

The company has passed the ISO9001:2015 international quality system certification, the trade mark “HF” is honored “Well-Known Trade Mark of Hebei Province”, meanwhile, the product is honored “Famous-Brand Product” by the Authority. The company is an export-oriented enterprise and the products are exported to more than 80 countries and regions, such as South Korea, Japan, America, Southeast Asia, Middle East and Africa and enjoyed a good reputation among customers. The company is dedicated to supply the best products and services to customers and would like to express sincere invitation to friends from all over the world.

HFAST

● Attaching metal framing for buildings or structures.
● Securing industrial machinery or equipment.
● Mounting heavy signage or displays.
● Installing handrails or guardrails.
Regular packing way

★ small box+carton
★ small bag+carton
★ bulk in carton
★ bulk in plastic box
